| RINOX TIG WIRE FOR GTAW PROCESS | |
| Size: | 1.20 mm – 6.00 mm |
| Surface : | Bright |
| Length : | 36" or 1000 mm |
| Embossing/Marking : | - To be embossed one side with GRADE & SIZES OR both Side with Grade &Sizes. |
| Packing : | In Plastic or Fibre Tubes of 5 kg or 10 lbs. |
| RELISH INOX Stainless Steel Tig Filler Wires strictly confirms to international standards like AWS, BS, EN, DIN, JIS, ETC which are supplied in bright finish. | |
| Grades : | 307, 307Si, 308, 308H, 308L, 308LSi 309, 309L, 309LSi, 309LMo 310, 312, 316, 316H, 316L, 316LSi, 317, 317Si, 318Si, 321, 347, 347Si, 409, 409Cb, 409Ti, 410, 410NiMo, 420, 430, 430LNb, 904L, 2209 |
| RINOX MIG WIRE FOR GMAW PROCESS | |
| Size: | 0.60 mm – 1.60 mm |
| Surface : | Bright ,Matte or Semi Bright |
| Packing : | 2 lbs/ 1 kg Wire ( SD 100) ,10 lbs/ 5 kg (SD 200) , 25lbs/33 lbs /44 lbs OR 12.5 /15 kg wire (SD 300) Plastic or BS 300 Basket spool. |
| Drum packing : | 100 kg /250 kg |
| Our MIG WIRES are manufactured in SS grades 307Si, 308L, 308LSi, 309, 309L, 309LSi, 309LMo, 310, 312, 316L, 316LSi, 317L, 318Si, 321, 347, 347Si, 409, 409Cb, 409Ti, 410, 410NiMo, 420, 430, 430LNb, 904L, 2209, 2597, 630 and nickel grades , NiCr-3 & NiCrMo-3 with bright, matte or semi bright finishes. Our stainless steel MIG wires are manufactured in sizes ranging from 0.60 mm to 1.60 mm diameter. | |
| RINOX SAW WIRE FOR SMAW PROCESS | |
| Size: | 1.60 mm – 5.00 mm |
| Surface : | Bright ,Matte |
| Packing : | 25 kg/ 60 Lbs .Layer wound coils with core or H 400 Plastic Spool or K415 METAL wire basket. |
| Drum packing : | 100 kg /250 kg |
| The welding wires manufactured by us are suitable for both automatic submerged arc welding machines and hand operated SAW guns. Our welding wires are manufactured for SS grades AISI 307, 307Si, 308, 308H, 308L, 308LSi, 309, 309L, 309LSi, 309LMo, 310, 312, 316, 316H, 316L, 316LSi, 317, 317Si, 318Si, 321, 347, 347Si, 409, 409Cb, 409Ti, 410, 410NiMo, 420, 430, 430LNb, 904L & 2209. We guarantees that SAW SS wires developed by them will provide yields and deliver the most advanced and productive welding products. | |
| STAINLESS STEEL CORE WIRE FOR MMAW PROCESS | |
| Size: | 1.60 mm – 5.00 mm |
| Surface : | Bright ,Matte |
| Packing : | Supplied in either in Coil Form or Cut -Length Required. |
| We have also developed specialized chemistries for core wires to enhance electrode producers flux requirements and weldability for end customer. Our Core Wires are manufactured in grades 307Si, 308L, 308LSi, 309, 309L, 309LSi, 309LMo, 310, 312, 316, 316L, 316LSi, 317L, 318Si, 321, 347, 347Si, 409, 409Cb, 409Ti, 410, 410NiMo, 420, 430, 430LNb, 904 L& 2209. | |
Welding Electrodes are meant as a metal wire that is coated with the same materials that is going to be welded. The electrode is generally known to build a contact between non metallic parts of the circuit, thus its principal has started being used in welding purposes. Therefore, these electrodes carry out current through a workpiece and fuse the two different parts together. Relying on its process, the electrodes are available in two forms either consumable in which gas arc welding is required or non-consumable where gas tungsten arc welding is involved.
| Types | |
| Mild Steel General Purpose Electrodes: | E6013, E7014, E7024 |
| Low Hydrogen Electrodes: | E7016, E7016-1, E7018, E7018-1, E7018-H4, E7018(NACE) |
| Low Alloy High Tensile Electrodes: | E7018-G, E7018-A1, E8018-G, E8018-W2, E8018-B2L, E8016-B6, E8018-C1, E9018-M, E9018-B3, E9018-G, E10016-G, E11018-M, E10018-D2 |
| Hard Facing Electrodes: | Electrodes suitable for weld metal with hardness 250BHN - 600BHN |
| Cast Iron Electrodes: | ENiFeCl, ENiCu, ENiCl |
| Stainless Steel Electrodes: | (available in -15, -16 & -17) E307-16, E308L-16, E309L-16, E309MoL-16, E310-16, E312-16, E347-16, E318-16, E410-16, E430-16, E309Cb-16 |
| Sizes/Diameter: | |||||
| mm | 1.60mm | 2.00mm | 2.50mm | 3.15mm | 3.20mm |
| inch | 0.063" | 0.079" | 0.098" | 0.124" | 0.126" |
| mm | 3.25mm 4.00mm 5.00mm | ||||
| 0.128" 0.157" 0.197" | |||||
| LENGTHS: |
| 250mm, 300mm, 350mm, 400mm, 450mm |
| Packaging | ||
| Plastic Tube | Vacuum/Pack | Master Carton |
| 2.5kg | 2kg & 5kg | 20kg |
